Features

1.Equipped with a fixed grantry and movable working stable,improves the stability and antivibration capability of the machine.

2.Welded structure by thick profiled steel,stabilized under high temperature,ensures minimum distortion,excellent rigidity and powerful strength.

3.The installation of vertical and horizontal drill and saw which can rotary 90' makes the machine a complete woodworking center in doors making.Confirguring of imported Carrousel tool magazine makes the process of tools changing rapid and accurate.

4.The special tool sensor enables the machine compensate the tolerance of the tool length accurataly.

5.Japan YASKAWA servo motor,high precision helicalrack,ensures the machine run stably with low noise,fast speed,and high positioning accuracy.

6.The vaccum stable adopts double cavity type adsorption.The use of high strength Bakelite board milled in one time ensures high adsorption power.

7.Strong Dust Collection systerm keeps the machine away from dust blowing when working.

8.Auto lubrication system,one touch can finish the periodic maintenance.

9.Optional Germany imported horizontal transform head,realized side processing.

Parameters
